Introduction Water flooding is the most conventional way to supplement formation energy in oil fields, and the effect of water flooding is directly related to the production capacity of oil fields. Under the premise of not changing the original packer structure, automatic control device of layered water flooding is added, and multiple sets of electronic water distribution devices are controlled step by step by special motor and deceleration device. Each set of electronic water distributor can adjust the opening and closing of different flow water spout of the water distributor at this level according to the control instructions on the ground, until it meets the requirements of water injection at the level. The application of this technology can be applied to the surface repeated allocation of water injection well, improve the scientific management of water injection well, and realize the efficient, reasonable and accurate water flooding purpose.
| Weight | 110kg |
| Length | 1800mm |
| OD | 114mm |
| ID | 60mm |
| Torque | 350N.M |
| Pressure | 70MPa |
Automatic filling valve is an automatic balance valve. There are two roles. The first is when the coil tubing goes in, automatically balance the internal and outer level of the string and its pressure. Prevent the tubing from being out.
Due to the progress of the production process of rubber tube, the performance of rubber tube is still gradually improving and developing. It can be setting in the casing or in the naked hole, either in a straight well or in a horizontal section, either in the conventional hole or in the key seated hole. […]
The Tool integrates the measurement modules of rotational speed, vibration and pressure to determine whether to release by detecting the rotational speed and vibration signal of the drilling tool, and then sending the pressure pulse signal from the surface to the bottom of the well to activate the tool. It adopts micro-motor rotation to drive the reversing valve set to switch the oil circuit and use the liquid column pressure to perform the releasing.
Introduction This is a downhole internal cutting tool using single/multi-core cable for power supply, which can be used for cutting downhole all types of downhole string with the advantages of accurate cutting point, smoothness and speed through the whole process of monitoring by the upper computer system. The system integrates 3 micro motors, 1 hydraulic […]
Introduction The electrical bypass circulation tool is a remote activated drilling tool using pressure wave control. The tool integrates a variety of micro motors, piston pumps, hydraulic valve sets and temperature and pressure sensors, and uses a high-temperature battery pack to supply power. The pressure sensor detects slight pressure pulse signal changes, identifies, processes and […]
Introduction Pump-based technology, multiple switching, sends commands to the slip sleeve by two methods, FSK pressure pulse or input magnetic ball, and the signal is detected by the built-in pressure sensor to control the micro-motor and micro-hydraulic system through the downhole logic terminal to realize the switching action of the slip sleeve. Weight 120kg Length […]
